SUZUKI

SUZUKI – power, efficiency, reliability and innovation!


Suzuki has been supplying the market with its outboard engines since 1965. Engines are powerful, durable and reliable.
They are suitable for all types of vessels – both smaller and larger.
They offer engines up to 350 hp of working capacity.

Label / meaning of the label

S

short leg – 381mm



L

long leg – 508mm



X

ultra-long leg – 635mm



XX

extra ultra long leg – 762mm



E

electric start-up, control lever



R

electric start-up, remote command



T

electric start-up, remote command, power trim



P

gearbox with adjustable direction of rotation



DF2.5

Advantages: OHV engine, digital CDI ignition system, 360° turn option, lightest in its category, Suzuki anti-corrosion protection, control lever with rubber handle, built-in fuel tank 1.0 L, gas resistance setting, steering resistance setting.

DF2.5S DF2.5L
Axis length S L
Number of cylinders 1 1
Engine volume 68 68
Fuel inlet Carburetor Carburetor
Weight (kg) 13.5 14
Fuel tank (L) 1.0 1.0

DF4

Advantages: possibility of laying in three positions, gravity fuel valve for easier start-up, digital CDI ignition system, immobilizer in gear, low oil pressure indicator, Suzuki anti-corrosion protection, oil filter for better lubrication, built-in fuel tank 1.5 L, connection for external tank, gas resistance setting, steering resistance setting.

DF4AS DF4AL
Axis length S L
Number of cylinders 1 1
Engine volume 138 138
Fuel inlet Carburetor Carburetor
Weight (kg) 23.5 24.5
Fuel tank (L) 1.5 1.5

DF5

Advantages: possibility of laying in three positions, gravity fuel valve for easier start-up, digital CDI ignition system, immobilizer in gear, low oil pressure indicator, Suzuki anti-corrosion protection, oil filter for better lubrication, built-in fuel tank 1.5 L, connection for external tank, gas resistance setting, steering resistance setting.

DF5AS DF5AL
Axis length S L
Number of cylinders 1 1
Engine volume 138 138
Fuel inlet Carburetor Carburetor
Weight (kg) 23.5 24.5
Fuel tank (L) 1.5 1.5

DF6

Advantages: possibility of laying in three positions, gravity fuel valve for easier start-up, digital CDI ignition system, immobilizer in gear, low oil pressure indicator, Suzuki anti-corrosion protection, oil filter for better lubrication, built-in fuel tank 1.5 L, connection for external tank, gas resistance setting, steering resistance setting.

DF6AS DF6AL
Axis length S L
Number of cylinders 1 1
Engine volume 138 138
Fuel inlet Carburetor Carburetor
Weight (kg) 23.5 24.5
Fuel tank (L) 1.5 1.5

DF8

The next-generation 4-stroke outboard engine features a new multi-function control lever with throttle control, cruise direction control (forward – idle – reverse), gas resistance setting and steering resistance setting. There is also a warning light on the lever that warns of low oil level and the over-exertion limiter.

DF8AS DF8AL
Axis length S L
Number of cylinders 2 2
Engine volume 208 208
Fuel inlet Carburetor Carburetor
Weight (kg) 39.5 42.0
Fuel tank (L) 12 12

DF9.9

Currently one of the most advanced portable engines on the market. The first model of this power that offers “Lean Burn” technology to reduce fuel consumption and “Battery – Less Electronic Fuel Injection” electronic fuel injection without battery. The DF9.9B features smooth running, quick start, excellent acceleration, good performance and low fuel consumption.
Advantages: OHC engine, Lean Burn system to reduce fuel consumption, electronic injection without battery, 32-bit computing unit, compression reduction to facilitate manual start-up, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector.

DF9.9BS DF9.9BL DF9.9BRS DF9.9BRL
Axis length S L S L
Number of cylinders 2 2 2 2
Engine volume 327 327 327 327
Fuel inlet EFI EFI EFI EFI
Weight (kg) 44.0 45.0 48.0 49.0
Fuel tank (L) 12 12 12 12

DF15

Currently one of the most advanced portable engines on the market. The first model of this power that offers “Lean Burn” technology to reduce fuel consumption and “Battery – Less Electronic Fuel Injection” electronic fuel injection without battery. The DF9.9B features smooth running, quick start, excellent acceleration, good performance and low fuel consumption.
Advantages: OHC engine, Lean Burn system to reduce fuel consumption, electronic injection without battery, 32-bit computing unit, compression reduction to facilitate manual start-up, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector.

DF15AS DF15AL DF15AES DF15AEL DF15ARS DF15ARL DF15ATL
Axis length S L S L S L L
Number of cylinders 2 2 2 2 2 2 2
Engine volume 327 327 327 327 327 327 327
Fuel inlet EFI EFI EFI EFI EFI EFI EFI
Weight (kg) 44.0 45.0 48.0 49.0 48.0 49.0 54.5
Fuel tank (L) 12 12 12 12 12 12 12

DF20

The DF20A is currently one of the most advanced portable engines on the market. It offers “Lean Burn” technology to reduce fuel consumption and “Battery – Less Electronic Fuel Injection” electronic fuel injection without battery. The DF20A features smooth running, quick start, excellent acceleration, good performance and low fuel consumption.
Advantages: OHC engine, Lean Burn system to reduce fuel consumption, electronic injection without battery, 32-bit computing unit, compression reduction to facilitate manual start-up, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector.

DF20AS DF20AL DF20AES DF20AEL DF20ARS DF20ARL DF20ATS DF20ATL
Axis length S L S L S L S L
Number of cylinders 2 2 2 2 2 2 2 2
Engine volume 327 327 327 327 327 327 327 327
Fuel inlet EFI EFI EFI EFI EFI EFI EFI EFI
Weight (kg) 44.0 45.0 48.0 49.0 47.0 48.0 52.5 54.5
Fuel tank (L) 12 12 12 12 12 12 12 12

DF25

The new 3-cylinder engine incorporates Suzuki’s best technology, placing it first among the competition. The DF25A is the lightest engine in its class. It is famous for its quiet and smooth running and excellent efficiency.
Advantages: OHC engine, Lean Burn system to reduce consumption, electronic injection without battery, integrated filter/fuel separator, compression reduction to facilitate manual start-up, Suzuki anti-corrosion protection, self-diagnostics system, warning for service interval, fresh water flush connector, CDI ignition system for quieter running.

DF25AS DF25AL DF25ARS DF25ARL DF25ATL
Axis length S L S L L
Number of cylinders 3 3 3 3 3
Engine volume 490 490 490 490 490
Fuel inlet EFI EFI EFI EFI EFI
Weight (kg) 62.0 63.0 65.0 66.0 72.0
Fuel tank (L) 25 25 25 25 25

DF30

The new 3-cylinder engine incorporates Suzuki’s best technology, placing it first among the competition. The DF30A is the lightest engine in its class. It is famous for its quiet and smooth running and excellent efficiency.
Advantages: OHC engine, Lean Burn system to reduce consumption, electronic injection without battery, integrated filter/fuel separator, compression reduction to facilitate manual start-up, Suzuki anti-corrosion protection, self-diagnostics system, warning for service interval, fresh water flush connector, CDI ignition system for quieter running.

DF30ATHL DF30ATS DF30ATL
Axis length L S L
Number of cylinders 3 3 3
Engine volume 490 490 490
Fuel inlet EFI EFI EFI
Weight (kg) 74.0 71.0 72.0
Fuel tank (L) 25 25 25

DF40

Advantages: DOHC engine, 4 valve technology, Lean Burn system to reduce consumption, timing chain instead of belt, integrated filter/fuel separator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running.

DF40ATS DF40ATL
Axis length S L
Number of cylinders 3 3
Engine volume 941 941
Fuel inlet EFI EFI
Weight (kg) 102 104

DF50

Advantages: DOHC engine, 4 valve technology, Lean Burn system to reduce consumption, timing chain instead of belt, integrated filter/fuel separator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running.

DF50ATS DF50ATL
Axis length S L
Number of cylinders 3 3
Engine volume 941 941
Fuel inlet EFI EFI
Weight (kg) 102 104

DF60

Advantages: DOHC engine, 4 valve technology, Lean Burn system to reduce consumption, timing chain instead of belt, integrated filter/fuel separator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running.

DF60ATL DF60AVTL
Axis length L L
Number of cylinders 3 3
Engine volume 941 941
Fuel inlet EFI EFI
Weight (kg) 102 114

DF70

Advantages: DOHC engine, 16 vents, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF70ATL
Axis length L
Number of cylinders 4
Engine volume 1502
Fuel inlet EFI
Weight (kg) 155

DF80

Advantages: DOHC engine, 16 vents, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF80ATL
Axis length L
Number of cylinders 4
Engine volume 1502
Fuel inlet EFI
Weight (kg) 155

DF90

Advantages: DOHC engine, 16 vents, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF90ATL DF90ATX
Axis length L X
Number of cylinders 4 4
Engine volume 1502 1502
Fuel inlet EFI EFI
Weight (kg) 155 158

DF100

Advantages: DOHC engine, 16 vents, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF100BTL DF100BTX DF100ATL DF100ATX
Axis length L X L X
Number of cylinders 4 4 4 4
Engine volume 1502 1502 2044 2044
Fuel inlet EFI EFI EFI EFI
Weight (kg) 155 158 182 187

DF115

Advantages: DOHC engine, 16 vents, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF115ATL DF115ATX
Axis length L X
Number of cylinders 4 4
Engine volume 2044 2044
Fuel inlet EFI EFI
Weight (kg) 182 185

DF140

Advantages: DOHC engine, 16 vents, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, fresh water flush connector, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF140ATL DF140ATX
Axis length L X
Number of cylinders 4 4
Engine volume 2044 2044
Fuel inlet EFI EFI
Weight (kg) 179 184

DF150

Advantages: digital command lever (TG model), DOHC engine, 16 valves, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF150ATL DF150ATX DF150APL DF150APX
Axis length L X L X
Number of cylinders 4 4 4 4
Engine volume 2867 2867 2867 2867
Fuel inlet EFI EFI EFI EFI
Weight (kg) 215 220 223 223

DF175

Advantages: digital command lever (TG model), DOHC engine, 16 valves, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF175ATL DF175ATX DF175APL DF175APX
Axis length L X L X
Number of cylinders 4 4 4 4
Engine volume 2867 2867 2867 2867
Fuel inlet EFI EFI EFI EFI
Weight (kg) 215 220 223 223

DF200

Advantages: digital command lever (TG model), DOHC engine, 16 valves, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF200ATL DF200ATX DF200APL DF200APX DF200TL DF200TX
Axis length L X L X L X
Number of cylinders 4 4 4 4 V6 V6
Engine volume 2867 2867 2867 2867 3614 3614
Fuel inlet EFI EFI EFI EFI EFI EFI
Weight (kg) 226 231 228 233 263 265

DF225

Advantages: V6 layout at an angle of 55°, DOHC engine, 24 valves, 32-bit computing unit, timing chain instead of belt, air-cooled high-performance alternator, multipoint sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF225TX
Axis length X
Number of cylinders V6
Engine volume 3614
Fuel inlet EFI
Weight (kg) 263

DF250

Advantages: digital command lever (AP model), DOHC engine, 24 valves, 4.0 L, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF250TX DF250TXX DF250APX DF250APXX
Axis length X XX X XX
Number of cylinders V6 V6 V6 V6
Engine volume 3164 3164 4028 4028
Fuel inlet EFI EFI EFI EFI
Weight (kg) 263 268 274 279

DF300AP

Advantages: digital command lever (AP model), DOHC engine, 24 valves, 4.0 L, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF300APX DF300APXX
Axis length X XX
Number of cylinders V6 V6
Engine volume 4028 4028
Fuel inlet EFI EFI
Weight (kg) 274 279

DF325

On the world market, the demand for outboard engines is growing. The biggest increase is right in the class of powerful engines. Many boat manufacturers decide to equip larger vessels, extending over a length of 12 m, with multiple outboard engines. As vessels get bigger, the engines need to get stronger. More and more often we meet vessels on which we can install not only two, but three or even four high-power outboard engines.
Making an engine with more power is no secret. The volume is increased and the turbocharger is added, so the engine has more power. Of course, more powerful engines consume more fuel, they are bigger and heavier, increasingly complex and reliability becomes a problem.
Regardless of the engine power, the speed of the vessel is always determined by the hull shape, hydrodynamic properties, propellers and the way the engine is installed on the vessel. Therefore, in constructing the new muscles at Suzuki, they decided to start constructing on a blank sheet of paper and to take all the above factors into account. First, they reviewed the existing solutions of single propeller outboard engines. The fact is that such an engine produces a lot of thrust but unfortunately as a by-product it causes a great deal of torque to the vessel due to the rotation of the propeller in one direction. In order to use this lost energy in a useful way, they quickly decided that it would be necessary to use two propellers that rotate in the opposite direction. Another problem of the drive is the transmission in front of the propellers, which hinders the ideal flow of water to the propellers. The higher the engine power and torque, the more powerful the transmission must be to transfer power from the engine driveshaft to the propeller shaft. Because of this, the transmissions are larger and their casing hinders the flow of water to thepropeller.
Suzuki has for years developed the engine, performed numerous tests and measurements in order to improve the way in which the power of the engine is best translated into the thrust of the water.

Advantages: Dual Prop System, DOHC engine, 24 valves, 4.3 L, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF325ATX DF325ATXX
Axis length X XX
Number of cylinders V6 V6
Engine volume 4390 4390
Fuel inlet EFI EFI
Weight (kg) 330 339

DF350

On the world market, the demand for outboard engines is growing. The biggest increase is right in the class of powerful engines. Many boat manufacturers decide to equip larger vessels, extending over a length of 12 m, with multiple outboard engines. As vessels get bigger, the engines need to get stronger. More and more often we meet vessels on which we can install not only two, but three or even four high-power outboard engines.
Making an engine with more power is no secret. The volume is increased and the turbocharger is added, so the engine has more power. Of course, more powerful engines consume more fuel, they are bigger and heavier, increasingly complex and reliability becomes a problem.
Regardless of the engine power, the speed of the vessel is always determined by the hull shape, hydrodynamic properties, propellers and the way the engine is installed on the vessel. Therefore, in constructing the new muscles at Suzuki, they decided to start constructing on a blank sheet of paper and to take all the above factors into account. First, they reviewed the existing solutions of single propeller outboard engines. The fact is that such an engine produces a lot of thrust but unfortunately as a by-product it causes a great deal of torque to the vessel due to the rotation of the propeller in one direction. In order to use this lost energy in a useful way, they quickly decided that it would be necessary to use two propellers that rotate in the opposite direction. Another problem of the drive is the transmission in front of the propellers, which hinders the ideal flow of water to the propellers. The higher the engine power and torque, the more powerful the transmission must be to transfer power from the engine driveshaft to the propeller shaft. Because of this, the transmissions are larger and their casing hinders the flow of water to thepropeller.
Suzuki has for years developed the engine, performed numerous tests and measurements in order to improve the way in which the power of the engine is best translated into the thrust of the water.

Advantages: Dual Prop System, DOHC engine, 24 valves, 4.3 L, Lean Burn system to reduce consumption, timing chain instead of belt, air-cooled high performance alternator, multi-point sequential electronic injection, Suzuki anti-corrosion protection, self-diagnostics system, service interval warning, CDI ignition system for quieter running, Suzuki trolling system (optional).

DF350ATX DF350ATXX
Axis length X XX
Number of cylinders V6 V6
Engine volume 4390 4390
Fuel inlet EFI EFI
Weight (kg) 330 339
